Accelerated performance for your most demanding tasks. The DE7200 allows you to run the most advanced software seamlessly and helps you create an immersive digital experience with powerful built-in visual enhancements. Integrating the latest 4th Generation Intel® Core™, the DE7200 raises the bar on computing. The versatile design of the DE7200 provides: - Support for Extended Desktop on all connected screens for up to three independent (Full HD) displays.
- Flexible integration opportunities thanks to a unique small form factor
- High performance support for Ultra HD resolution (4k*)
- Power switch extension for remote control
- Ultra reliable hardware with 24/7 operability
- Energy efficient green computing
AOPEN Digital Engine DE7200 - Realize 4K Ultra HD application
-
-
- Specification
-
-
| -
- Model
-
| -
- DE5100I
-
| -
- Dimension:
-
| -
- inch : 6.54 x 1.89 x 6.18 (W x H x D inch)
-
| -
- Volume:
-
| -
- 1.25L
-
| -
- CPU:
-
| -
- Socket : Socket G3/rPGA946
Type : Supports 4th generation Intel® Core™ vPro™ i3, i5, i7 mobile processor TDP≤47W -
| -
- Chipset:
-
| -
- Intel® QM87 Chipset
-
| -
- Memory:
-
| -
- Channels: Dual Channel
Type : DDRIII Low Voltage SO-DIMM x2
Speed Grade : 1333/1066Mbps
Max memory : 16G (based on OS support) -
| -
- Graphics:
-
| -
- Chip : Intel HD Graphics 4600
HDMI Port x2
Display Port x1 -
| -
- Expansion Slot:
-
| -
- mini Card Slot : x 2 (Full size x1, half size x1)
-
| -
- Audio:
-
| -
- Type : Realtek HD Audio Codec ALC269Q
Channel : Stereo 5.1 CH with HDMI -
| -
- LAN:
-
| -
- Intel® Gigabit Ethernet WGI217LM, 10/100/1000Mbps
-
| -
- Storage Bay:
-
| -
- SATA Connector x1 (2.5" SATA HDD)
mSATA x1 -
| -
- Front Panel IO:
-
| -
- Powerbutton: x1
HDD indicator (blue): x1
Power indicator (blue): x1
USB 2.0 port: x2 -
| -
- Rear Panel IO:
-
| -
- DC Jack : x 1
HDMI Port: x2
Display Port : x 1
USB 2.0 Port : x2 (combined with eSATA)
USB 3.0 Port : X 2
eSATA: x2
RJ-45 LAN Jack : x 1
Legacy RS232 Serial Port (COM Port) : x 1
Audio Set Line-Out : x 1
Audio Set Mic-In : x 1
Upgrade for Antenna Port : x 2
Kensington Lock Hole : x 1 -
| -
- CPU Thermal Module:
-
| -
- AOPEN Thermal Mode, Noise (idle mode): 27dB
-
| -
- WatchDog Timer:
-
| -
- 1 ~ 255 sec/min
-
| -
- Adapter:
-
| -
- 90W (19/12V, 4.5A) AC Adapter
-
| -
- Input Voltage:
-
| -
- AC 100 ~ 240V/DC 12V/20V
-
| -
- Environment:
-
| -
- MTBF : 50,000hrs
Operating Temperature : 0 ~ 50°C (32 ~ 122°F)
Storage Temperature : -30 ~ 60ÂşC (-22 ~ 140ÂşF)
Relative Humidity : 95% RH (50°C non-Condensing)
Operating Vibration: 0.5Gms, Random, 10~500Hz,X,Y,Z 3 Axes,0.5hr/Axis
Non-Operating Vibration: 2Gms,Random,10~300Hz,X,Y,Z 3 Axes,1hr/Axis
Operating Shock: 8G,Half sine,11 ms duration
Non- Operating Shock: 50G, Half sine, 11ms duration -
| -
- Support OS:
-
| -
- Windows 7 Pro/Ultimate : V
Windows XP : V
Windows XP Embedded : V
Windows Embeddeb Standard 2009 (WES2009) : V
Windows Embedded Standard 7 (WES7E) : V
Windows Embedded Standard 7 (WES7P) : V -
|
|
|
|
